For more technical information on our SPEL separators please click here to go to our SPEL Separator Solutions page.
200 Series
NS 4 – NS 10
300 Series
NS 15 – NS 50
400 Series
NS 65 – NS 300
500 & 600 Series
Sizes/specifications and performance data available on request.
Wash Down Separators must discharge to foul subject to water company approval.
If BS EN 858 Compliance is required, please click here to see SPEL Class 2 Separators.
Designed with reference to BS EN 13121. All tank shells carry the SPEL 25 Year Warranty and life expectancy in excess of 50 years.
Different tank shell specifications are available dependent upon tank invert levels, ground conditions and ground water levels. (See Installation Guidance section)
160/225/300mm diameter PVCU socket/spigot.
450mm diameter GRP spigot only. For connecting to site pipework Flex-Seal/Band-Seal or similar flexible couplings can be used.
The nine inlet/outlet options below are available to assist with design and installation.
| Model | Series | Max. Flow* | Silt Capacity (L) | Overall Length* | Internal Diameter (mm) | Opt In/Out Pipe Diameter (mm) | Number of Access Shafts (dia. mm) | Inlet Invert (mm) |
|---|---|---|---|---|---|---|---|---|
| Flow (l/s) | L | 600 | A | |||||
| WDS 200/1000 | 200 | 1.1 | 250 | 1.17 | 1,200 | 160mm | 1 | – |
| WDS 200/2000 | 200 | 2.2 | 500 | 2.05 | 1,200 | 160mm | 1 | – |
| WDS 200/3000 | 200 | 3.3 | 700 | 2.93 | 1,200 | 160mm | 1 | – |
| WDS 200/4000 | 200 | 4.5 | 1,000 | 3.82 | 1,200 | 160mm | 1 | – |
| WDS 200/5000 | 200 | 5.6 | 1,250 | 4.7 | 1,200 | 160mm | 1 | – |
| WDS 200/6000 | 200 | 6.7 | 1,500 | 5.59 | 1,200 | 160mm | 1 | – |
| WDS 200/7000 | 200 | 7.8 | 1,750 | 6.48 | 1,200 | 160mm | 1 | – |
| WDS 200/8000 | 200 | 9 | 2,000 | 7.36 | 1,200 | 160mm | 1 | – |
| WDS 200/9000 | 200 | 10 | 2,250 | 8.25 | 1,200 | 160mm | 1 | – |
| WDS 200/10,000 | 200 | 11 | 2,500 | 9.13 | 1,200 | 160mm | 1 | – |
| WDS 300/4000 | 300 | 5 | 1,000 | 1.95 | 1,800 | 160mm | 1 | – |
| WDS 300/6000 | 300 | 7 | 1,500 | 2.76 | 1,800 | 160mm | 1 | – |
| WDS 300/8000 | 300 | 9 | 2,000 | 3.54 | 1,800 | 160mm | 1 | – |
| WDS 300/10,000 | 300 | 12 | 2,500 | 4.29 | 1,800 | 160mm | 1 | – |
*Based on 80% removal using Millisil W4 Test Sediment.
Note: all Wash Down Separators must be connected to the foul drainage network.
All SPEL Separator Systems have a large range of technical accessories to ease maintenance and monitoring.
Circular access shafts are supplied in 450, 600, 700, 900 and 1200mm diameter. Rectangular shafts are supplied in 800, 900 and 1000mm X 1000/1250/1500mm. GRP ladders can be incorporated for more access, complete with stainless steel fixings.
Shafts can be laminated onto the tank up to a maximum height of 1.2m. Above this height extension shafts can be supplied separately for on-site fitting during installation.
Shafts up to 400mm high are laminated onto the tank. Above this height extension shafts can be supplied separately for on-site fitting during installation.
Shafts up to 300mm high are laminated onto the tank. Above this height extension shafts can be supplied separately for on-site fitting during installation.
Stub access shafts are fitted 100mm high and extension access shafts fitted as 500 series. Above this height extension shafts can be supplied separately for on-site fitting during installation.
These are supplied in 500mm increments and are available in different laminate specs to suit site-specific invert levels and applications.
Note: only applicable to units fitted with the SPEL Coalescer
Normal servicing of the smaller SPEL Separators frequently requires emptying the unit completely. Guide rails provide access for the coalescer units to be taken out, cleaned and returned and guided accurately to their seating positions. However larger SPEL Separators may only require the hydrocarbon pollutants and silt to be removed.
In order to limit the servicing to sucking off the fuel/oil from the top and the silt from the bottom guide rails are required to ensure coalescer units are replaced into their correct positions.
The system is robust, manufactured throughout in stainless steel and the action positive, leaving no doubt the coalescer unit is located properly.
Brackets fixed to the top and bottom of the coalescer unit simply engage the stainless steel guide rail fixed to the top of the stub access shaft. The coalescer is then lowered in the normal way, being guided at the correct angle into the conical base unit which locates the coalescer unit into its final position.
Extension guide rails can be incorporated into SPEL extension shafts to suit (preferably when ordered with the separator).
SPEL coalescer units lowered into the separator with the SPEL guide rail system are easily guided into the base unit’s conical moulding to automatically sit correctly.
However, when the separator is full of water, debris or silt accumulated over a period, this could prevent the coalescer unit from re-seating correctly after servicing.
The coalescer unit lifting/locating/locking system provides assurance the coalescer unit is seated correctly and can be locked into position to prevent tampering.
The system is particularly suitable in SPEL Separator + Econoskim® systems where the total contents of the separator are not emptied on servicing.
The system comprises a robust stainless steel lifting and lowering handle that locates on the guide rail system. When the coalescer unit is correctly located in the conical seating in the separator, the handle will align with guide rail top bracket i.e.. the handles slotted holes with the top bracket clip locking groove, see diagram.
When aligned the stainless steel clip can be located through the slots and lock into position on the top bracket.
The stainless steel lifting handle can be extended to suit deep tank inverts and provide easy access for lifting manually or with the SPEL tripod and hoist.
For silt, oil and high level detection, compatible with the below alarm probes.
Available with optional flashing beacon, and GMS/ SMS communication, also compatible with the below alarm probes.
Dedicated alarm system for the full range of SPEL Grease Separators.
Detects oil and indicates when the treatment system’s oil storage is full.This probe is required in order for a treatment device to comply with BS EN 858.
Monitors the silt layer in the treatment system and indicates when the silt layer has reached its maximum level.
Indicates when the liquid level in the treatment system rises excessively e.g. in an outlet blockage situation.
Where surface water run-off has a high silt content the coalescer units can become filled, making them heavy to lift out. In order to facilitate easy withdrawal of coalescer units the SPEL tripod and hoist is recommended.
